X 50
X pumps

Use

Use and maintenance manual

The best solution for the suction and transfer of liquids, thanks to the strong self-priming ability, the ability to run even with discontinuous presence of the liquid in suction and the reversibility of the flow, is easy to install and use. The X series pumps are made of CB 754S brass with stainless steel shaft. They are supplied with hose connectors. This model is provided with a multiplier (ratio 1: 6) for coupling to 1 ”3/8 rotating PTOs at low speed. For each application, it is necessary to check the suitability and choose appropriate gaskets.

The product are particularly suitable for use:

agriculture (fungicides, liquid fertilizers, components on agricultural machinery, irrigation)
transports (tankers, road machines, on board water systems)

Hydraulic specifications

Maximum capacity : 360 lt/min
Maximum head : 25 m
Gasket on the shaft: Seal
Maximum priming height : 6 m
Threaded ports: 2"
Maximum liquid density 1.1g/cm³ free of hard particles in suspension
Maximum temperature 90°C
Not suitable for aggressive liquids towards pump construction materials and gaskets (see technical specifications)
Not appropriate for the transfer of petrol, solvents and, in general, in environments with risk of explosion and fire
Possibility of reversing the pumping flow
Complete with a pair of brass hose fittings for pipes 50 (one straight and one curved)
Possibility of working for short periods with closed pipes
During installation, the pump must be filled with liquid, subsequently this operation is no longer necessary
